Sicut valvae fabricandi supplementum integrationis R&D, designationis, productionis, venditionis, et muneris, JQF Valvae officinas technicas turmas et qualitatem administrationis integram gloriatur. Fructus nostri late in variis agris utuntur ut petroleum, chemica, potentia plantae, tutelae environmentalis, fodienda carbonis, adficio, et nova vis. Princeps qualitas pressurae globi chalybis immaculati valvulae altae ad vetustatem et constantiam destinatae sunt, variis instrumentis et temperie condicionibus aptae. Perfectionem continenter prosequimur et integritati omnique emptori committimus, praestantibus fructibus et officiis praebendo. Nos sincere suscipimus novas et veteres clientes visitare, vocare, scribere ad negotia tractanda.
1. Valvae caulis materialis virtus alta, valvae corpori arcte connexa, rotationem levem et operationem facilem procurans.
2. Cochleae diligenter selectae ut nexum strictum, validum, et aerugo repugnans efficiant.
3. Incorrupta valvae chalybeis corpus praebet altum pressuram globus chalybe immaculatam valvulae bonam corrosionem resistentia et rubigo praeventionis.
4. Lingae densatae fiunt ex materia solida et firmiter connexa.
1. Commodum et Velox
Simplex structura, facile fabricare et conservare.
2. Fast Switching, parva actio
Plaga brevis laborat, celeritas aperiendi et claudendi responsio.
3. Dura
Stricta sigillum, obsistens et robusta, longa vita servit.
Design specification: GB/T 12235
Structura longitudinis: GB / T 12221
Connexio Linga: JB/T 79
Test et inspectio: JB / T 9002
Product identificatio: GB / T 12220
Supple specificationem: JB / T 7928
| Nominal diameter | Praecipua externae mensurae et nexus dimensiones | |||||||
| L | D | D1 | D2 | b | Z-d | H | D0 | |
| J41H-16C | ||||||||
| 15 | 130 | 95 | 65 | 45 | 14-2 | 4-Φ14 | 170 | 120 |
| 20 | 150 | 105 | 75 | 55 | 14-2 | 4-Φ14 | 190 | 140 |
| 25 | 160 | 115 | 85 | 65 | 14-2 | 4-Φ14 | 205 | 160 |
| 32 | 180 | 135 | 100 | 78 | 16-2 | 4-Φ18 | 270 | 180 |
| 40 | 200 | 145 | 110 | 85 | 16-3 | 4-Φ18 | 310 | 200 |
| 50 | 230 | 160 | 125 | 100 | 16-3 | 4-Φ18 | 358 | 240 |
| 65 | 290 | 180 | 145 | 120 | 18-3 | 4-Φ18 | 373 | 240 |
| 80 | 310 | 195 | 160 | 135 | 20-3 | 8-Φ18 | 435 | 280 |
| 100 | 350 | 215 | 180 | 155 | 20-3 | 8-Φ18 | 500 | 300 |
| 125 | 400 | 245 | 210 | 185 | 22-3 | 8-Φ18 | 614 | 320 |
| 150 | 480 | 280 | 240 | 210 | 24-3 | 8-Φ23 | 674 | 360 |
| 200 | 600 | 335 | 295 | 265 | 26-3 | 12-Φ23 | 811 | 400 |
| 250 | 650 | 405 | 355 | 320 | 30-3 | 12-Φ25 | 969 | 450 |
| 300 | 750 | 460 | 410 | 375 | 30-3 | 12-Φ25 | 1145 | 580 |
| 350 | 850 | 520 | 470 | 435 | 34-4 | 16-Φ25 | 1280 | 640 |
| 400 | 980 | 580 | 525 | 485 | 36-4 | 16-Φ30 | 1452 | 640 |
| J41H-25C | ||||||||
| 15 | 130 | 95 | 65 | 45 | 16-2 | 4-Φ14 | 170 | 120 |
| 20 | 150 | 105 | 75 | 55 | 16-2 | 4-Φ14 | 190 | 140 |
| 25 | 160 | 115 | 85 | 65 | 16-2 | 4-Φ14 | 205 | 160 |
| 32 | 180 | 135 | 100 | 78 | 18-2 | 4-Φ18 | 270 | 180 |
| 40 | 200 | 145 | 110 | 85 | 18-3 | 4-Φ18 | 310 | 200 |
| 50 | 230 | 160 | 125 | 100 | 20-3 | 4-Φ18 | 358 | 240 |
| 65 | 290 | 180 | 145 | 120 | 22-3 | 8-Φ18 | 373 | 240 |
| 80 | 310 | 195 | 160 | 135 | 22-3 | 8-Φ18 | 435 | 280 |
| 100 | 350 | 230 | 190 | 160 | 24-3 | 8-Φ23 | 500 | 300 |
| 125 | 400 | 270 | 220 | 188 | 28-3 | 8-Φ25 | 614 | 320 |
| 150 | 480 | 300 | 250 | 218 | 30-3 | 8-Φ25 | 674 | 360 |
| 200 | 600 | 360 | 310 | 278 | 34-3 | 12-Φ25 | 811 | 400 |
| 250 | 650 | 425 | 370 | 332 | 36-3 | 12-Φ30 | 969 | 450 |
| 300 | 750 | 485 | 430 | 390 | 40-4 | 16-Φ30 | 1145 | 580 |
| 350 | 850 | 550 | 490 | 448 | 44-4 | 16-Φ34 | 1280 | 640 |
| 400 | 980 | 610 | 550 | 505 | 48-4 | 16-Φ34 | 1452 | 640 |
